Rugged Alloy Steel HDD Hole Opener With Removable Cut

Product Categories

Langfang pangolin construction machinery co. LTD

Contact Now

Rugged Alloy Steel HDD Hole Opener With Removable Cut

Ask Lasest Price
Brand Name :	Pangolin
Price :	Negotiation
Payment Terms :	T/T
Delivery Time :	5-15 work day

Add to Cart

Product Details
Company Profile

Rugged Alloy Steel HDD Hole Opener With Removable Cut

Rugged Alloy Steel With Removable Cut To HDD Hole Opener

Description:

Fixed diameter taps are made of robust heat-treated alloy steel for maximum strength. The surface of the cutter arm with movable cutter is hardened and welded to the main body. There are three types of milling cutters: SM for soft to medium molding, MH for medium to hard forming, XH for hard forming. The tapper has three or six nozzles with replaceable nozzles, so the spray can quickly clean enlarged holes.

Product name	HDD hole opener
Usage	horizontal directional drilling
Weight	200kg-400kg
MOQ	1
Application formation	medium hard with relatively higher compressive strength and hard stringers, such as hard shale, sandstone and limestone, etc.

Reamer Size	Cone size and # of Cones				Threads
Reamer Size	Cone size	#of Cones	Cone size	# of Cones	Threads
10“	6 1/2”	3			NC23 NC26(2 3/8IF) D50 D80 NC31(2 7/8IF) NC38(3 1/2IF)
12“	8 1/2”	3			NC23 NC26(2 3/8IF) D50 D80 NC31(2 7/8IF) NC38(3 1/2IF)
16“	8 1/2”or 9 1/2”	4			For 8 1/2”-9 1/2” Cone: NC23 NC26(2 3/8”IF) D50 D80 NC31(2 7/8”IF) NC38(3 1/2”IF) For 12 1/4”-13 5/8” Cone: 4”IF 4 1/2IF 5 1/2FH 6 5/8FH
18”-20“		5	12 1/4”	4
22”-24“		6	12 1/4” or 13 5/8”	5
28”-30”		7		6
32”-34”		8		7
36“-38”		9		8
40“-42”		10		9
44“-46”		11		10
48”-50”		12-13		11

Machine Type	Drilling Equipment
Use	Well Drilling
Application	HDD reamer
Usage	Hole Drilling
Advantage	High Performance Cost Ratio
Applicable Industries	Construction works , Energy & Mining

FAQ

1. How to order products?
A: Direct order!

2. How to control quality?
A: we should check and test everyone's bit before shipment.

3. Do you agree to order samples?
A: Yes, we welcome your sample order to test our quality.

4. Can we choose the color of drill bit?
A: Yes, we have blue, gold, silver and other colors for you to choose from. If you need, we can make the drill color according to your requirements.
